Open Flare: The open Flare is used to burn the unnecessary landfill gas and digest gas. In many occasions it is also used to deodorize odour.

Photo Gallery

Product Description

Main Features

Model	Max.Capacity （Nm3/h)	Flange connect	Pressure	Size(D*H)	Mounting Dimensions	Mounting holes	Ignition electrodenumber	Weight(kg)
FLAME-50	50	DN40/PN10	＞2KPa	?400*5000	?460	8-M30	1	300
FLAME-100	100	DN50/PN10	＞2KPa	?500*5000	?460	8-M30	1	360
FLAME-200	200	DN65/PN10	＞2KPa	?500*6000	?460	8-M30	1	600
FLAME-300	300	DN80/PN10	＞2KPa	?600*8000	?500	8-M30	1	700
FLAME-400	400	DN100/PN10	＞2KPa	?650*8000	?500	8-M30	1	850
FLAME-600	600	DN125/PN10	＞2KPa	?800*8000	?700	8-M30	1	1050
FLAME-800	800	DN150/PN10	＞2KPa	?900*8000	?800	8-M30	1	1200
FLAME-1000	1000	DN150/PN10	＞2KPa	?1000*8000	?900	8-M30	1	1600
Note: Consult factory for different media, can be specific selection

Double Probe type high-voltage ignition,high reliability

Temperature detection

Flame arrester

Flame protection

Naturally with purge wind

Stainless steel flare disc and burner

Specifications:

Methane concentration: 30%-60%

Combustion temperature: 300-1200℃

Turn down range: 20%-100%

Inlet gas pressure: > 2Kpa

Model Max.Capacity
（Nm3/h) Flange connect Pressure Size(D*H) Mounting Dimensions Mounting holes Ignition electrodenumber Weight(kg)

FLAME-50 50 DN40/PN10 ＞2KPa ?400*5000 ?460 8-M30 1 300

FLAME-100 100 DN50/PN10 ＞2KPa ?500*5000 ?460 8-M30 1 360

FLAME-200 200 DN65/PN10 ＞2KPa ?500*6000 ?460 8-M30 1 600

FLAME-300 300 DN80/PN10 ＞2KPa ?600*8000 ?500 8-M30 1 700

FLAME-400 400 DN100/PN10 ＞2KPa ?650*8000 ?500 8-M30 1 850

FLAME-600 600 DN125/PN10 ＞2KPa ?800*8000 ?700 8-M30 1 1050

FLAME-800 800 DN150/PN10 ＞2KPa ?900*8000 ?800 8-M30 1 1200

FLAME-1000 1000 DN150/PN10 ＞2KPa ?1000*8000 ?900 8-M30 1 1600

Note: Consult factory for different media, can be specific selection
